Hệ thống giữa máy chủ Dell T340 và Dell T350 có gì khác nhau?

Chiều rộng: 218 mm (8.58″)

Chiều sâu: 603 mm (23.7″)

Chiều rộng: 175 mm (6.89″)

Chiều sâu: 581.12 mm (22.88″)

• 1x USB 3.0
• 1x iDRAC micro USB 2.0 management port

Rear Ports

• 2x USB 3.0
• 4x USB 2.0, VGA, serial connector

Internal ports

• 1 x USB 3.0

• 1 x Dedicated iDRAC (Micro-AB USB) port
• 1 x USB 3.0

Rear Ports

• 5 x USB 2.0
• 1 x iDRAC dedicated port
• 1 x USB 3.0
• 1 x VGA
• 1 x Seria

Internal ports

• 1 x USB 3.0 (Optional)

• 4 x PCIe Gen 3 Slots

• 2 x Gen 4 PCIe slots
• 2 x Gen 3 PCIe slots

• 1 processor Intel® Xeon® E-2200 product family, Intel Pentium®, Intel Core i3®, Intel Celeron®

• One Intel Xeon E-2300 Series processor with up to 8 cores, or Intel Pentium processors with up to 2 cores

• 4x DDR4 DIMM slots, supports UDIMMs, speeds up to 2666MT/s, 64GB max.
• supports registered ECC

• 4 DDR4 DIMM slots, supports UDIMM 128 GB max, speeds up to 3200 MT/s
• Supports registered ECC DDR4 DIMMs only
• For Pentium processor, maximum memory speed supported is 2666 MT/

• Internal controllers: PERC H330, H730p, HBA330
• External controllers: 12 Gbps SAS HBA
• Internal Boot: BOSS: 2 x M.2 240 GB (RAID 1 or No RAID) and 1 x M.2 240 GB (No RAID only)
• Software RAID: S140

• Internal controllers: PERC H345, PERC H355, HBA355i, PERC H755
• External HBA (non-RAID): HBA355e
• Internal Boot: BOSS-S2: HWRAID 2 x M.2 SSDs
• Software RAID: S150

• Up to 8 x 3.5” hot-pluggable bays
• Also supports 2.5” HDD in 3.5” hybrid drive carrier)

• Up to 4 x 3.5-inch SAS/SATA (HDD/SSD)
• Up tp 8 x 3.5-inch SAS/SATA (HDD/SSD)
• Max 160 TB on 8 HDD configuration
• Supports 2.5-inch drive in 3.5-inch hybrid drive carrier.

• 2x Hot-Plug-Redundant 495W PSUs or Single Cabled 350W PSU

• 450 W Bronze (cabled) AC/100 – 240 V
• 600 W Platinum AC/100 – 240 V
• 600 W DC/240 V
• 700 W Titanium AC/100 – 240 V
• 700 W DC/240 V

• iDRAC9
• iDRAC Direct

• iDRAC9
• iDRAC Direct
• iDRAC RESTful with Redfish
• iDRAC Service Module
